30 Apr 2020 08:01 #8162 by Ricardo
3D shading was created by Ricardo
Good morning,
I want to simulate the losses of two arrays which I draw in the 3D shade calculator. I would like to import the loss of both arrays to the system but I still have the same warning over and over:
WARNING: You have 2 subarrays enabled and 1 subarray in the 3D scene.
I do have 2 different arrays in the 3D model and i do not understand why is taking just 1.
Thank you.
Ricardo López.

Please Log in or Create an account to join the conversation.

  • Paul Gilman
More
04 May 2020 22:22 #8173 by Paul Gilman
Replied by Paul Gilman on topic 3D shading
Hi Ricardo,

Be sure to set the Subarray property for each active surface to match the Subarray number on the System Design page:



Best regards,
Paul.
Attachments:
