Getting weird jagged lines on PV-Battery heatmap

Start
Prev
1
Next
End

Aproop
Topic Author

28 Nov 2023 09:50 #12698 by Aproop

Getting weird jagged lines on PV-Battery heatmap was created by Aproop

Hi folks

I've just run a grid-connected PV battery system with a custom load. I used default sizing options for the PV modules, inverter, and battery and used the peak shaving algo for battery dispatch. Why am I getting this weird jagged line output on the file?

Please Log in or Create an account to join the conversation.

Paul Gilman

28 Nov 2023 18:09 #12699 by Paul Gilman

Replied by Paul Gilman on topic Getting weird jagged lines on PV-Battery heatmap

Hi Aproop,

I'm not sure what you mean by "weird jagged line output on the file." If you need help troubleshooting, please tell me what output variable you are plotting, and if possible attach a .sam file or screenshot so I can understand your question.

Best regards,
Paul.

Please Log in or Create an account to join the conversation.

Aproop
Topic Author

29 Nov 2023 06:30 - 30 Nov 2023 22:37 #12701 by Aproop

Replied by Aproop on topic Getting weird jagged lines on PV-Battery heatmap

Thanks Paul: I attached the .png file in my original post, pasted here for ease: also attaching the sam file.

1.sam

Last edit: 30 Nov 2023 22:37 by Paul Gilman. Reason: Insert image as attachment

Please Log in or Create an account to join the conversation.

Paul Gilman

30 Nov 2023 23:27 #12708 by Paul Gilman

Replied by Paul Gilman on topic Getting weird jagged lines on PV-Battery heatmap

Hi Aproop,

This is a rendering problem with SAM's data viewer for data with sub-hourly time steps. I created an issue on GitHub: github.com/NREL/SAM/issues/1616

Thank you for letting us know about this.

Best regards,
Paul.
